产品概述
产品优势
Safe and Reliable
Gantry-type engine block with grid structure and forged steel crankshaft.
Proprietary ECU and data software.
Dual-circuit cooling system with titanium plate heat exchangers and pure copper seawater pump.
Global supply chain network with rigorous quality inspection.
Powerful Performance
Wide power range with over 20% torque reserve and rapid acceleration response.
High torque reserve to accommodate both low-speed/high-load and high-speed/high-load operating conditions.
Economical and Fuel-Efficient
Fuel system from world-renowned manufacturers, providing high fuel pressure and injection precision.
Mature fuel injection control system enabling multiple injections, including pre-injection and main injection, for excellent atomization and complete combustion.
Comfortable and Environmentally Friendly
Water-cooled turbocharger and water-jacketed exhaust manifold designed to reduce engine room temperatures.
Proven diesel engine NVH optimization technology for low vibration and noise.
产品规格
备注：产品参数及图片仅供参考；如有变动，不另行通知。
Commercial Ratings
|
Engine series |
Model |
Power(kW/Ps) |
Speed(r/min) |
Technical route |
Aspiration |
Emission |
Rating |
Fuel |
|
6M33 |
6M33C550-15 |
404/550 |
1500 |
Mechanical |
TA |
IMO Tier Ⅱ |
P1 |
MGO |
|
6M33 |
6M33C600-18 |
441/600 |
1800 |
Mechanical |
TA |
IMO Tier Ⅱ |
P1 |
MGO |
|
6M33 |
6M33C650-18 |
478/650 |
1800 |
Mechanical |
TA |
IMO Tier Ⅱ |
P1 |
MGO |
|
6M33 |
6M33C700-18 |
515/700 |
1800 |
Mechanical |
TA |
IMO Tier Ⅱ |
P1 |
MGO |
|
6M33 |
6M33C750-18 |
551/750 |
1800 |
Mechanical |
TA |
IMO Tier Ⅱ |
P2 |
MGO |
|
6M33 |
6M33C750-18E211 |
552/750 |
1800 |
Common rail |
TA |
IMO Tier Ⅱ |
P1 |
MGO |
|
6M33 |
6M33C830-18E211 |
610/830 |
1800 |
Common rail |
TA |
IMO Tier Ⅱ |
P2 |
MGO |
|
6M33 |
6M33C912-19E211 |
670/912 |
1900 |
Common rail |
TA |
IMO Tier Ⅱ |
P3 |
MGO |
|
6M33 |
6M33C1020-20E211 |
750/1020 |
2000 |
Common rail |
TA |
IMO Tier Ⅱ |
P4 |
MGO |
|
12M33 |
12M33C1000-15 |
735/1000 |
1500 |
Mechanical |
TA |
IMO Tier Ⅱ |
P1 |
MGO |
|
12M33 |
12M33C1200-18 |
882/1200 |
1800 |
Mechanical |
TA |
IMO Tier Ⅱ |
P1 |
MGO |
|
12M33 |
12M33C1300-18 |
956/1300 |
1800 |
Mechanical |
TA |
IMO Tier Ⅱ |
P1 |
MGO |
|
12M33 |
12M33C1400-18 |
1029/1400 |
1800 |
Mechanical |
TA |
IMO Tier Ⅱ |
P1 |
MGO |
|
12M33 |
12M33C1500-18 |
1103/1500 |
1800 |
Mechanical |
TA |
IMO Tier Ⅱ |
P2 |
MGO |
|
12M33 |
12M33C1400-18E211 |
1030/1400 |
1800 |
Common rail |
TA |
IMO Tier Ⅱ |
P1 |
MGO |
|
12M33 |
12M33C1500-18E211 |
1104/1500 |
1800 |
Common rail |
TA |
IMO Tier Ⅱ |
P2 |
MGO |
|
12M33 |
12M33C1650-18E211 |
1214/1650 |
1800 |
Common rail |
TA |
IMO Tier Ⅱ |
P3 |
MGO |
|
16M33 |
16M33C1750-16E211 |
1287/1750 |
1600 |
Common rail |
TA |
IMO Tier Ⅱ |
P1 |
MGO |
|
16M33 |
16M33C1850-16E211 |
1361/1850 |
1600 |
Common rail |
TA |
IMO Tier Ⅱ |
P2 |
MGO |
|
16M33 |
16M33C1950-18E211 |
1434/1950 |
1800 |
Common rail |
TA |
IMO Tier Ⅱ |
P1 |
MGO |
|
16M33 |
16M33C2100-18E211 |
1545/2100 |
1800 |
Common rail |
TA |
IMO Tier Ⅱ |
P2 |
MGO |
Remark: The delivery date of model with * should be negotiated specifically
