Precise control, high reliability, and high power density.
Suitable for hydraulic bulldozers, road rollers, pavers, truck cranes, dust suppression vehicles, mixer trucks, harvesters, crawler cranes, horizontal directional drills, forage harvesters, road sweepers, boom pump trucks, marine machinery, crushers, and oil fracturing trucks.
额定压力 bar
最大排量 cc/rev
产品概述
The 02 series features load-independent control logic; regardless of the control method used, machine performance remains consistent with control inputs. The precision of the 02 series control systems effectively enhances overall system efficiency and ease of operation. We offer various control options, including electronic, hydraulic, and mechanical, while integrating features such as torque control and pressure cut-off protection.
产品优势
Compact design.
High power density.
Fast dynamic response.
High reliability.
Long service life.
Noise optimization.
High control precision, independent of load.
产品规格
|
Parameters |
55 |
75 |
80 |
95 |
105 |
135 |
165 |
210 |
280 |
|
Max. displacement (cc/rev) |
54.7 |
75.9 |
80 |
95 |
105 |
135.7 |
165.6 |
210.1 |
281.9 |
|
Max. operating speed (rpm) |
3900 |
3400 |
3200 |
3100 |
3200 |
3000 |
2750 |
2300 |
2400 |
|
Max. speed (instantaneous) (rpm) |
4150 |
3600 |
3400 |
3300 |
3400 |
3200 |
2950 |
2500 |
2550 |
|
Rated pressure (bar) |
450 |
450 |
420 |
420 |
450 |
450 |
450 |
450 |
450 |
|
Max. pressure (instantaneous) (bar) |
500 |
500 |
450 |
450 |
500 |
500 |
500 |
500 |
500 |
|
Allowable case pressure (bar) |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
|
Torque (N·m) |
374 |
519 |
497 |
590 |
719 |
929 |
1133 |
1438 |
1929 |
|
Power (kW) |
153 |
185 |
166 |
191 |
241 |
292 |
326 |
346 |
485 |
|
Weight (approx.) (hydraulic control, case drained) (kg) |
46 |
49 |
49 |
49 |
66 |
72 |
113 |
132 |
164 |
备注：产品参数及图片仅供参考；如有变动，不另行通知。
