产品概述
All open-circuit pumps are optimized for pulsation characteristics to facilitate noise reduction. In addition to standard measures such as optimized valve plates, we offer an SPU noise reduction unit for open-circuit variable pumps. This unit reduces system pressure pulsation by up to 70% without compromising pump functionality or efficiency, regardless of pressure, speed, or temperature changes. The SPU system provides self-adaptive noise reduction across the entire operating range, requiring no setup or maintenance.
产品优势
In combination with the Weichai hydraulic directional valve and control system, it can form a machining LSC synchronous control system.
Synchronization control system.
Demand-based flow distribution with no overflow loss, ensuring system energy efficiency.
Rapid response speed.
High self-priming capability within the rated speed range.
Optimized noise reduction design.
Compact structure.
High power density ratio.
High reliability.
Long service life
产品规格
|
Parameters |
55 |
75 |
95 |
105 |
135 |
165V |
165V+ |
165 |
210 |
249 |
280 |
105D |
125D |
165D |
|
Max. displacement (cc/rev) |
55 |
75.9 |
94.7 |
105 |
135.7 |
163.6 |
163.6 |
165.6 |
210.1 |
249.9 |
281.9 |
210 |
2×125 |
2×165 |
|
Max. operating speed (without pressurized reservoir) (rpm) |
2700 |
2500 |
2500 |
2500 |
2350 |
2400 |
2400 |
2200 |
2100 |
2250 |
2000 |
2450 |
2400 |
2100 |
|
Max. flow (L/min) |
148.5 |
189.8 |
237.5 |
246.8 |
312.1 |
392.6 |
392.6 |
364.3 |
441.2 |
563 |
563.8 |
514.5 |
600 |
695.5 |
|
Rated pressure (bar) |
420 |
420 |
350 |
420 |
420 |
350 |
350 |
420 |
420 |
350 |
420 |
420 |
350 |
420 |
|
Max. pressure (instantaneous) (bar) |
500 |
500 |
420 |
500 |
500 |
420 |
420 |
500 |
500 |
420 |
500 |
500 |
420 |
500 |
|
Allowable case pressure (bar) |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
|
Torque (N·m) |
368 |
507 |
528 |
702 |
907 |
911 |
911 |
1107 |
1404 |
1392 |
1884 |
1245 |
1392 |
1964 |
|
Rated power (theoretical) (kW) |
104 |
132.8 |
138 |
172.7 |
218.5 |
229 |
229 |
255 |
308.8 |
328 |
394.7 |
319.4 |
337 |
431.8 |
|
Weight (approx.) (case drained) (kg) |
39 |
39 |
44.5 |
50 |
65 |
74 |
75 |
91.5 |
116 |
125 |
165 |
96 |
113 |
177 |
备注：产品参数及图片仅供参考；如有变动，不另行通知。
