产品概述
Hande drive axles offer leading advantages in reliability and lightweight design, with core components featuring maintenance-free configurations to deliver maximum value to users.
产品优势
High efficiency: Enhanced system efficiency and superior energy recovery contribute to a range increase of over 10%.
High reliability: The axle housing utilizes new high-strength materials, and gear profile modification effectively reduces contact stress, resulting in a service life extension of over 10%.
Extended maintenance-free intervals: No initial maintenance required, long oil-change intervals of 120,000/300,000 km for the main reducer, and maintenance-free wheel ends.
产品规格
|
Rated Axle Load (kg) |
13000 |
|
Rated Torque (N·m) |
40000 |
|
Gear ratio |
2.714~5.286 |
|
Target applications |
New Energy Tractor Units (GCW ≤ 80t) |
备注：产品参数及图片仅供参考；如有变动，不另行通知。
