6M16 Series Industrial Engine

Reliable, durable, with high environmental adaptability and low maintenance costs.

Suitable for low-pressure water pumps, high-pressure water pumps, air compressors, and oil & gas fields

190-255

功率范围 kW/Ps

1489/1400

最大扭矩/转速 N·m / r/min

产品手册下载服务图标

服务支持

立即询价产品咨询

/Products & Businesses/Energy & Power/Industrial Power

概述优势规格型谱表

产品概述

The 6M16 engine features a 9.726L displacement with a power range of 190-255 kW. It meets non-emission requirements and is applicable to industries such as low-pressure water pumps, oil & gas fields, flatbed transporters, and cementing units.

产品优势

Features mechanical governing for rapid response and high stability, with enhanced tolerance to harsh environments and varying fuel quality.

Core components, including the engine block and crankshaft, are manufactured from high-strength materials for superior wear resistance and impact toughness.

The Pump-Drive power pack is equipped with a high-efficiency radiator, ensuring stable power output in high-temperature environments (45℃).

Simplified design allows for easy disassembly and installation, facilitating daily maintenance and repairs.

产品规格

功率范围 kW/Ps

190-255

最大扭矩转速 N·m / r/min

1489/1400

排放标准

Zero emission

产品系列

燃料

Diesel

发动机型式

In-line

气缸数/气门数

6/2

缸径 × 行程mm

排量 L

9.726

进气方式

Turbocharged and air-to-air intercooled

压缩比

燃烧系统

发动机尺寸（长X宽X高） mm

1756×961×1168

G重量 kg

875

备注：产品参数及图片仅供参考；如有变动，不另行通知。

型谱表

Model	Displacement (L)	Rated power/speed (kW/rpm)	Peak torque/speed (N·m/rpm)	Governing System	Emission standard
6M16V4D0	9.726	190/2200	1225/1300-1500	Mechanical governor	Zero emission
6M16V6D0	9.726	240/1800	1489/1400	Mechanical governor	Zero emission
6M16V2D0	9.726	255/2200	1380/1400-1500	Mechanical governor	Zero emission
