1500kVA-2000kVA Land-based Standard Generator Set

Application scenarios Data centers, power plants, oilfields and mines

1200、1500、1600

功率范围/持续功率

Open type

结构形式

产品手册下载服务图标

服务支持

立即询价产品咨询

/Products & Businesses/Energy & Power/Generator Set/Overseas Heavy Fuel Oil

概述优势规格型谱表

产品概述

The WH25 series engine is a new generation of large-bore engine crafted by Weichai using cutting-edge design concepts.

产品优势

Safe and reliable: Advanced engine design concept, high-strength engine block, cylinder head, crankshaft, and connecting rod, with a long diesel engine overhaul interval.

Good fuel economy: Efficient combustion balancing power output, superior performance, and low fuel consumption.

High practicality: Integrated design with individual cylinder heads allows easy assembly and disassembly of complete units with low maintenance cost.

Highlights

Large-bore strong power output, heavy fuel oil compatibility, mature and stable technology

产品规格

持续功率kWe

1200、1500、1600

产品系列

燃料

Diesel, HFO

发动机型式

Inline, four-stroke, water-cooled engine

气缸数

缸径 × 行程mm

250×330

排量 L

机组尺寸（敞开式）mm

7500×2366×3400

重量（开式）kg

38000

结构形式

Open type

备注：产品参数及图片仅供参考；如有变动，不另行通知。

型谱表

Generator set model	Engine Model	Displacement (L)	Number of valves per cylinder	Continuous power / speed(kWm/rpm)	Generator set continuous power (kVA/kWe)	Technology roadmap
WPG1650B3	6WH25LD1350-7.5	97	4	1350/750	1500/1200	Mechanical unit pump
WPG2200B3	6WH25LD1800-1	97	4	1800/1000	2000/1600	Mechanical unit pump
WPG1320B3	6WH25LD1350-7.2	97	4	1350/720	1500/1200	Mechanical unit pump
WPG1650B3	6WH25LD1620-9	97	4	1620/900	1875/1500	Mechanical unit pump

1500kVA-2000kVA Land-based Standard Generator Set

1200、1500、1600

Open type
