Weichai Landking G3

最大流量 L/min

额定流量 L/min

产品手册下载服务图标

概述优势规格型谱表

产品概述

产品优势

High efficiency and powerful performance

All-new Weichai W2.5NQ180E62, with torque up to 500 N·m, dynamic performance improved by 4%–12%, and fuel saving by 7%–15%.

High-efficiency SCR route, completely eliminating the risks of EGR blockage and breather icing.

Strong load-carrying capacity

Full high-strength steel double-layer frame, 215×800 mm double-layer longitudinal beam section, 610L material for longitudinal and cross beams.

10T rear axle, strong load-carrying capacity.

Flexible and efficient

2800/2950 short wheelbase, turning radius less than 7 m.

Reserved for 110 mm cylinder bore dual front-end hydraulic cylinder modification, dump angle 45° ± 2°.

Strong lifting capacity and flexible operation

Front axle Φ320×160, rear axle Φ320×160 brakes, stable performance and safe.

Air brake, reliable braking, powerful braking force.

Fast 10-speed transmission, reliable performance, with crawler gear, sufficient power for heavy-load climbing.

产品规格

Cab	1860single-row/half-rowcab
Wheelbase	2800	2950
Engine	WP2.5NQ180E62
Transmission	FAST10JS90A-B
Frontaxle	Ratedpayload5T
Rearaxle	Ratedpayload10T/widetrack
Frame	800×215double-layerstraight-throughbeam
Leafspring	8/10+10
Tire	8.25R16LT18PR(tube-type)

备注：产品参数及图片仅供参考；如有变动，不另行通知。
